MMA-210 Series
Compact sensor magnets in cylindrical housing
The MMA‑210 series sensor magnets are robust and durable, specifically designed for clamp or plug-in mounting. They are ideal for use in industry, electronics, and automation, providing reliable magnetic force even under demanding conditions.
The resistant PA66GF housing ensures stability and easy integration into a wide variety of systems.
The resistant PA66GF housing ensures stability and easy integration into a wide variety of systems.
Do you require a customized solution?
Individual customizations:
• Housing shape
• Magnetic strength
• Material
• Housing shape
• Magnetic strength
• Material
Areas of application
Position control, speed measurement, level measurement
Features
Actuating magnet
Neodymium or ferrite
Customized adjustments possible
Series characteristics
Product information for the series
A neodymium or ferrite-based activation magnet. The housing design allows for clamp or plug-in mounting. Available with different magnetic strengths and temperature resistances.
Operating temperature: –20°C … +105°C
Housing material: PA66GF
Magnet: NdFeB N35H / Ferrite Y35
Approval
REACH; RoHS
Technical drawing
Variant characteristics
| MMA‑210 -1 | MMA‑210 -2 | |||
|---|---|---|---|---|
| Dimensions | Ø 5.6 × L 25.2 mm | Ø 5.6 × L 25.2 mm | ||
| Temperature range | –20°C … +105°C | –20°C … +105°C | ||
| Material | PA66GF | PA66GF | ||
| Magnet type | NdFeB N35H | Ferrite Y35 | ||
| Mounting | Clamp or plug-in mounting | Clamp or plug-in mounting | ||
| Small quantities & samples |
 To the shop
|
To the shop
|
| Property | MMA‑210 -1 | MMA‑210 -2 | – | – |
|---|---|---|---|---|
| Dimensions | Ø 5.6 × L 25.2 mm | Ø 5.6 × L 25.2 mm | ||
| Temperature range | –20°C … +105°C | –20°C … +105°C | ||
| Material | PA66GF | PA66GF | ||
| Magnet type | NdFeB N35H | Ferrite Y35 | ||
| Mounting | Clamp or plug-in mounting | Clamp or plug-in mounting | ||
| Small quantities & samples |
To the shop
|
To the shop
|
◀ Please scroll table sideways ▶
