Fork Reed Sensors
Fork reed sensors feature an integrated magnetic actuator and switch only when an element passes through the gap between the magnet and the reed switch. They are available in various contact types and are ideal for position, limit, and rotational motion detection in industrial applications.
Wired
MMS-501
Dimensions: L 11.4 x W 2.7 mm
Contact Form: A-Normally Open
Operating Temperature: -20°C…+80°C
Switching Power: 10W
Areas of application
Position Control, Contactless Switching
All Advantages at a Glance
Precise Switching Point Detection:
The sensor responds only when positioned precisely in the fork gap, enabling high accuracy.
Contactless Switching Function:
Since no mechanical contact is required, wear is minimal.
Easy Integration:
The compact design with integrated magnet enables quick and straightforward installation.
Versatile Contact Options:
Normally open, normally closed, changeover, and high-voltage contacts cover various requirements.
High Electrical Load Capacity:
Switching loads up to 265 VAC or 300 VDC at 10 VA are easily achievable.
Reliable in Harsh Environments:
The sensor operates reliably even under dirt, moisture, or vibration.
Do you need a customized solution
for your product?
Dimensions and Shape
Mounting / Modification
Magnetic Sensitivity
Operating Temperature
Connection Types
Housing Material
