MMA-110 Series
Compact Sensor Magnet for Versatile Applications
The MMA‑110 flat housing sensor magnet is robust and durable, suitable for use in industry, electronics, and automation. Thanks to its particularly compact design and resistant PA66GF housing, it can be easily integrated into existing systems and flexibly mounted via screw or adhesive attachment.
Do you require a customized solution?
Individual Customizations:
• Housing shape
• Magnet strength
• Material
• Housing shape
• Magnet strength
• Material
Application Areas
Position control, speed measurement, level measurement
Features
Actuating magnet
Neodymium or Ferrite
Custom adaptations possible
Series Characteristics
Product Information for the Series
A neodymium or ferrite-based activation magnet. The housing design allows for screw or adhesive mounting. Available with different magnet strengths and temperature resistances.
Operating temperature: –20 °C … +105 °C
Housing material: PA66GF
Magnet: NdFeB N35H / Ferrite Y35
Approval
REACH; RoHS
Technical drawing
Variant Characteristics
| MMA‑110 -1 | MMA‑110 -2 | |||
|---|---|---|---|---|
| Dimensions | L 19 × W 11.3 × H 4.5 mm | L 19 × W 11.3 × H 4.5 mm | ||
| Temperature range | –20 °C … +105 °C | –20 °C … +105 °C | ||
| Material | PA66GF | PA66GF | ||
| Magnet type | NdFeB N35H | Ferrite Y35 | ||
| Mounting | Screw or adhesive mounting | Screw or adhesive mounting | ||
| Small quantities & samples | Please inquire directly | |||
| Property | MMA‑110 -1 | MMA‑110 -2 | – | – |
|---|---|---|---|---|
| Dimensions | L 19 × W 11.3 × H 4.5 mm | L 19 × W 11.3 × H 4.5 mm | ||
| Temperature range | –20 °C … +105 °C | –20 °C … +105 °C | ||
| Material | PA66GF | PA66GF | ||
| Magnet type | NdFeB N35H | Ferrite Y35 | ||
| Mounting | Screw or adhesive mounting | Screw or adhesive mounting | ||
| Small quantities & samples | Please inquire directly | |||
◀ Please scroll table horizontally ▶
